CLEANING BRUSH
· Works well for removing particles of soil and
other debris from sampling tubes
CAA PN131
SUBSOIL PROBE
· Punches through soil like a powered probe
· Can penetrate packed earth roadbeds, hard
clay, soil containing limestone gravel, and
frozen soil
· Requires only one technician for operation
· Facilitates sampling in areas where electricity
or hydraulic operation is compromised
CAA PN425
MASTER EXTENSION
· Master extension for PN425
(Environmentalist's Sub-Soil Probe Plus)
· Reliable hole and cross pin connections
· Lets user sample to 6'
· 9.0 lbs.
CAA PN428
PIN EJECTION TOOL
· Removes crosspins quickly and easily from
extensions for the sub-soil probe
· Prevent hand injuries
· Reduce chances of losing crosspins
· Nickel-plated metal parts to protect against
rust and wear
CAA PN230
ENVIRONMENTALIST'S
SUBSOIL PROBE
· Punches through soil like a power probe and
penetrates packed earth, roadbeds, hard clay,
soil containing limestone gravel, and frozen soil
· Facilitates sampling in areas where electricity
or hydraulic operation is compromised
or prohibited
· Standard sampling tube pulls soil sample in
one plunge and captures every sample in a
PETG copolyester (or optional stainless
steel) liner
· Samples to depths of 3' to 21' with extensions
· 12-1/2 lb. slide hammer drives sampling tube
into the ground and the foot-operated jack
pumps tube out of the ground
· Liners may be sealed with supplied vinyl caps
to facilitate shipping samples to user's lab
· Can be decontaminated quickly in the field
· Includes:
(1) environmentalist's subsoil probe
(1) 36" sampling tube with 2 tips
(1) slide hammer assembly
(1) cleaning brush
(1) core extraction tool
(1) owner's manual
(15) PETG copolyester
(2) cutting tips for normal and wet soils
(36) inch liners
(30) vinyl caps
CAA PN150
MASTER EXTENSION
· Master Extension for PN150
(Environmentalist's Sub-Soil Probe)
· Reliable hole and cross pin connections
· Lets user sample up to 6' with the PN150
· 4.5 lbs
CAA PN157
REGULAR EXTENSION
· Regular extension for PN150
(Environmentalist's Sub-Soil Probe)
· Reliable hole and cross pin connections
· Lets user sample 9' with the PN150 (must
use master extension first and each additional
extension adds 3')
· 3.5 lbs.
CAA PN158
POCKET SOIL
PENETROMETER
· Divisions are every 1/4 tons per square foot,
from 0 tons to 4-1/2 tons per square foot
HUM H4200
8" x 5/8"
4 oz.
MUNSELL SOIL
COLOR CHARTS
· Used for classifying the colour of various soils
and rocks
· Approximately 200 matte colour chips are
permanently mounted on charts for basic
collection of 7 hues (10R to 5Y) with apertures
between chips to facilitate observations
· Looseleaf binder format furnished with colour
name diagrams, instructions and
viewing masks
FOS 77341
4-1/4" x 7-1/2"
SAND CHART
· Flexible, waterproof plastic card with sand
grains fused to plastic
· Compact gauge is loaded with sand specifics
· Features:
Roundness chart
Size classification for large clasts
Size classification from silt to very coarse
Bed thickness classifications
Field checklist to organize notes
Geologic time scale
(2) carbonate classification charts
CGS 9300
2-1/2" x 3-1/2"
GEOTECHNICAL GAUGE
SAND CHART
· Flexible, waterproof plastic card that contains
miscellaneous data for soil use
· Sand grains and colour chips permanently
fused to the plastic
· Printed on both sides
· Features:
Roundness chart
Percentage composition estimation chart
Unified soil classification system
(6) common Munsell soil colours
Soil compaction tests for clay sand
Size classification with sand grains from coarse
to silt
CGS 9303
5" x 7"
