GOLD PAN & RELIC SIEVE
· Screens out waste gravel over 3/8"
KEE SGP1
16"
CLASSIFYING SIEVES
· For sizing material and gold
· Constructed of high impact plastic and a
stainless steel screen
· Designed to fit over 5 gallon pail
KEE CS2
2 mesh
KEE CS4
4 mesh
KEE CS8
8 mesh
KEE CS12
12 mesh
KEE CS20
20 mesh
KEE CS30
30 mesh
KEE CS50
50 mesh
KEE CS100
100 mesh
WHITE PLASTIC SIEVES
· Screen is heat welded to the plastic frame
· Eight spoked wagon wheel rings in bottom
of sieve prevents metal mesh from stretching
4" DIAMETER SIEVES
PEC PP14510
10 mesh
PEC PP14520
20 mesh
PEC PP14540
40 mesh
PEC PP14580
80 mesh
PEC PP14977
Catch pan
7" DIAMETER SIEVES
PEC PP14010
10 mesh
PEC PP14020
20 mesh
PEC PP14030
30 mesh
PEC PP14040
40 mesh
PEC PP14080
80 mesh
PEC PP14492
Catch pan
SIEVE
CATCH PAN
MOTORIZED SIEVE SHAKER
DUA D4325
115 V
60 Hz
ROCKSAW
· Electric Baldor motor
· Dual capacitor increases power efficiency
and reduces run amperage, making it an ideal
machine for low voltage conditions
· Capable of cutting 8" x 8" x 16" blocks
· Sta-level
®
blade guard keeps the blade guard
parallel to the cutting table for accurate cuts
HSQ GM1451
5 hp
220 V
CLASSIFYING SIEVES
· Classifies material before processing it through
sluice box or gold pan users
· Made of high impact, blue plastic and 1/2"
stainless steel mesh
· Conveniently sized to fit over most five gallon
buckets and can be stacked with other sieves
for graduated classification
KEE BCS2
#2 mesh
KEE BCS4
#4 mesh
KEE BCS8
#8 mesh
KEE BCS12
#12 mesh
KEE BCS20
#20 mesh
KEE BCS30
#30 mesh
KEE BCS50
#50 mesh
KEE BCS100
#100 mesh
BRASS FRAME SIEVES
· Sieves are constructed of specially woven and
selected wire cloth
· Brass frames with brass woven cloth
DUA US3-10S
3" dia. 10 mesh
1-3/4" high
DUA US3-18S
3" dia. 18 mesh
1-3/4" high
DUA US3-35B
3" dia. 35 mesh
1-3/4" high
DUA US3-35S
3" dia. 35 mesh
1-3/4" high
DUA US3-60S
3" dia. 60 mesh
1-3/4" high
DUA US3-100S
3" dia. 100 mesh 1-3/4" high
DUA US3-140B
3" dia. 140 mesh 1-3/4" high
DUA US3-270S
3" dia. 270 mesh 1-3/4" high
DUA US8-10FB
8" dia. 10 mesh
2-7/8" high
DUA US8-18FB
8" dia. 18 mesh
2-7/8" high
DUA US8-35HB
8" dia. 35 mesh
2-7/8" high
DUA US8-35FB
8" dia. 35 mesh
2-7/8" high
DUA US8-80FB
8" dia. 80 mesh
2-7/8" high
DUA SP3-1
Bottom pan for 3" sieves
DUA SP8-2
Bottom pan for 8" brass frame sieves
DUA SC3
Flat cover for 3" brass frame sieves
DUA SC8
Flat cover for 8" brass frame sieves
SIEVE
BOTTOM PAN
FLAT COVER
MANUAL CORE SPLITTER
· Splits core lengthwise
· Handles core diametres from 3/4" to 2-7/8"
and lengths up to 3-3/4"
POT 9326
POT 14549
Replacement blades
