DOUBLE TIE-IN
MICRO PULLEY
· Ideal for arborist rigging where two tie-ins
are required
· Purple anodized aluminum sideplates
· 1-1/4" aluminum sheave
CMT RP141
1/2" rope cap.
7,000 lbs.
Avg. Strength
CABLE-ABLE PULLEY
· For hostile environments
· Blue anodized side plates
· 2-3/8" aluminum sheave
CMT RC103
5/8" rope cap.
6,000 lbs.
Avg. Strength
MICROPULLEY WITH
ALUMINUM SHEAVE
· Purple anodized side plates
· 1-1/4" aluminum sheave
CMT RP110
1/2" rope cap.
7,000 lbs.
Avg. Strength
PRUSIK MINDER PULLEY
· Large diameter aluminum sheave mounted on
sealed ball bearings for excellent efficiency
PEZ P60
.
8,000 lbs.
Avg. Strength
ARBORIST PULLEY
· Designed for use in false crotch systems to
help save wear on bull ropes
· Upper bushing accommodates slings up
to 3/4"
· Lower sheave accepts bull ropes up to 5/8"
diameter on a 4" block
· 6" block accepts bull ropes up to 3/4"
CMT RP130
6-1/2" x 4"
MBS 28,000 lbs
CMT RP131
7" x 5"
MBS 40,000 lbs.
STAINLESS STEEL PULLEY
· Excellent pulley for speed lining
· 5/8" maximum rope diameter and capacity
· 3" sheave
CMT RP105
6-1/2" x 4-1/4" MBS 16,000 lbs.
MICRO PULLEY
· Micro pulley rescue model with purple
anodized sideplates
· Nylon sheave
· Sintered bronze bushing
· 1/2" rope capacity
CMT RP109
2-3/4" x 1-17/20"
MBS 7,000 lbs.
SERVICE LINE PULLEY
· Stainless steel single sheave pulley
· 1/2" rope capacity
CMT RP118
5" x 2-1/2"
MBS 8,000 lbs.
DOUBLE-ENDED PULLEY
· Stainless steel single sheave pulley
· Lower attachment point allows pulleys to
be rigged in block and tackle fashion in
mechanical advantage systems
· Tagline can be attached to guide a load
· 5/8" rope capacity
CMT RC105
6" x 3-1/4"
MBS 8,500 lbs.
PORTABLE CAPSTAN WINCH
· 5,000 lbs. of portable pulling power
· Up to 4X faster than electric winches
· Attaches to tree, pole or trailer hitch
· Reliable 50 cc, 4 cycle engine
· Full range of accessories available
PWC 5000
33 lbs.
ASCENSION ROPE GRAB
· Handle with ergonomic grip for comfort and
thermal insulation
· For single ropes between 8 mm and 13 mm
in diameter
PEZ B17L
Left handed
PEZ B17R
Right handed
MICROGRAB ROPE
CLAMP/GRAB
· Permanently installed on the rope which
prevents accidental disengagement of the
device and simplifies use
· An essential component of an adjustable
work-positioning lanyard
· For use on single 9 mm to 13 mm rope
PEZ B53
