F534 SERIES FIBREGLASS
EXTENSION LADDER
· CSA Grade 1, ANSI Type 1A, 300 lb. rated
· Non-conductive fibreglass rails
· Solid rivet construction
· Heavy-duty self-aligning safety feet with slip
resistant threads and steel ice pick plate
· Heavy-duty aluminum pulley
· 1-5/8" aluminum "D" rungs with serrated
surface for safety and comfort
· Rungs attach directly to rails using
protective washers
· Polyethylene rung sleeves to reduce wear and
extend life
· Heavy-duty spring assisted rung locks
PART #
SIZE
EXTENDED LENGTH
STU F53416
16'
13'
STU F53420
20'
17'
STU F53424
24'
21'
STU F53428
28'
25'
STU F53432
32'
29'
STEEL TRAY WHEELBARROW
· Heavy-duty industrial wheelbarrow
· Rolled edge, seamless steel tray
· Welded tray clips and funnel tray with easy
pouring lip
· Four-ply 16" pneumatic tire with inner tube
· Roller bearings with zerk fitting
· Oversized 3/4" steel axle
· Heavy-duty steel undercarriage with tray
braces, leg stabilizers, stays and leg
shoe pads
· 600 lb. capacity
GNT TIFS600
6 cu. ft. cap.
16" x 4" wheel
POLY TRAY WHEELBARROW
· Heavy-duty industrial wheelbarrow
· Corrosion proof poly tray, steel front tray
braces and H-brace
· 16" wheel assembly with pneumatic two-ply
tire with ball bearing
· 5/8" steel axle and leg stabilizers
· 60" hardwood handles
· 368 lb. capacity
GNT MP575T22BB
5-3/4 cu. ft. cap. 16" x 4" wheel
TYPE 3 FLAT EYE AND
EYE SLING
· Eye is formed by folding back the webbing
and sewing it flat against the body
PART #
WEBBING
RATED
CAP.
(vertical)
DIMENSIONS
DBI EE1901YNT34
Nylon / 1-ply
1,600 lbs.
4' x 1"
DBI EE1901YNT36
Nylon / 1-ply
1,600 lbs.
6' x 1"
DBI EE1902YNT36
Nylon / 1-ply
3,200 lbs.
6' x 2"
DBI EE2901YNT32
Nylon / 2-ply
3,100 lbs.
2' x 1"
DBI EE2901YNT38
Nylon / 2-ply
3,100 lbs.
8' x 1"
DBI EE2902YNT310
Nylon / 2-ply
6,200 lbs.
10' x 2"
DBI EE2902YNT312
Nylon / 2-ply
6,200 lbs.
12' x 2"
ELECTRONIC LEVEL AND
CARRYING CASE
· Digitally displays degrees, percent slope and
pitch to 1/10 degree accuracy
· Extremely durable and has push button
calibration
· Features audio sound at level and plumb
MCD 92288
SmartTool
60 cm
MCD 92296
SmartTool
120 cm
MCD 92908
Carry case
60 cm
MCD 92924
Carry case
120 cm
ELECTRONIC MODULE
· Sensor module digitally displays degrees,
percent slope and pitch to 1/10 degree
accuracy
· Audio sound at level and plumb
· Module can be used alone or with carpentry
and construction levels (regular and magnetic)
MCD 92346
MAGNETIC BRACKET
· Designed exclusively for use with SmartTool
sensor module
· Magnetic placement of SmartTool increases
speed and efficiency
MCD 92395
2 HP WATER PUMP
· 164' total head (total height at sea level,
to which water can be raised above original
water level)
· Self priming pump for easy operation
· Super low noise muffler
· Three-vane impeller with semi-open design for
efficient water flow
· Powered by Robin Engines, engine model
number EC04D
· 1" suction / discharge diametre
· 164' / 27' total / suction head
· 7,800 LPH / 2,081 GPH maximum
pumping capacity
· 50:1 fuel mixture
· Standard equipment included:
Tool kit (530- 90030-00)
Strainer (480-02550-29)
MAK EW100R
9.6 oz. fuel tank cap.
