PIPE SIZE ADJUSTABLE Z DEAD STOP WITH EXPANSION JOINT
Patent #8,863,932
www.nolinmilling.com · sales@nolinmilling.com
5/16" EMBU
Ceramic Chip
1/4"
Ceramic Tile
1/4"
UHMW
1/2"
Black Rubber
1/4"
EMBU Blue
5/16"
EMBU Orange
1/4" AR
Steel
5/16"
EMBU Blue
WHEN ORDERING, CHOOSE YOUR IMPACT PLATE
PATENTED PIPE SIZE ADJUSTABLE Z DEAD STOP WITH EXPANSION JOINT
patent #8,863,932. This Pipe Size
Adjustable Z Dead Stop with Expansion Joint has no internal baffle. You select the type of replaceable impact plate for
your application. Unit comes with access panel for inspection of wear and for replacement of impact plate. Unit will adjust
from 35° to 60°. Replaceable impact plate is at a 35° angle allowing for a moving pile to form when material flow is
sufficient. Unit is designed for free-flowing dry bulk material.
Choose your impact plate for your application. Unit is 7 gauge construction and comes with 7 gauge square to round on
discharge. Your choice of impact plate is included in price. Replacement impact plates available. Primed gray.
View of Access
©2018
Features
1. Combines the features of an Expansion Joint and
Adjustable Z Dead Stop, making it easier to install.
2. Oversized receiver accepts downspout without
welding. This assures proper alignment with
downspout. Eliminates need for precise cutting
and flanging, reducing installation time.
3. Easy to Install:
· Slip weather cover on incoming downspout.
· Insert incoming downspout to spout stop.
· Adjust to angle needed.
· Tighten hood bolts. Caulk hood.
· Tighten bolts on incoming expansion joint
weather cover.
4. An A-frame may be needed. Incoming spout may
need to be supported.
Shown at
35°
Shown at
60°
Size
Price
6
5/8
"
$589.00
8
5/8
"
639.00
10
3/4
"
899.00
12
3/4
" 1,029.00
REPLACEMENT IMPACT PLATES
Size
Price
6
5/8
"
$129.00
8
5/8
"
189.00
Size
Price
10
3/4
"
$189.00
12
3/4
"
249.00
P.O. Box 156 · 101 Pine St.
Dickens, IA 51333
NOLIN MILLING, INC.
INCOMING SPOUT RUN
12 GA. WEATHER COVER
1/4" THICK
RECEIVING SLEEVE
ACCESS
PANEL
INCOMING
SPOUT STOP
REPLACEMENT
IMPACT PLATE
ADJUSTS FROM
35° TO 60°
