SQUARE IN ADJUSTABLE Z DEAD STOP
Patent #8,863,932
www.nolinmilling.com · sales@nolinmilling.com
5/16" EMBU
Ceramic Chip
1/4"
Ceramic Tile
1/4"
UHMW
1/2"
Black Rubber
1/4"
EMBU Blue
5/16"
EMBU Orange
1/4" AR
Steel
5/16"
EMBU Blue
WHEN ORDERING, CHOOSE YOUR IMPACT PLATE
PATENTED SQUARE IN ADJUSTABLE Z DEAD STOP
patent #8,863,932. This Square In Adjustable Z Dead Stop
has no internal baffle. You select the type of replaceable impact plate for your application. Unit comes with access
panel for inspection of wear and for replacement of impact plate. Unit will adjust from 35° to 60°. Replaceable impact
plate is at a 35° angle allowing for a moving pile to form when material flow is sufficient. Unit is designed for
free-flowing dry bulk material.
Choose your impact plate for your application. Unit is 7 gauge construction and comes with 7 gauge square to square
on discharge. Your choice of impact plate is included in price. Replacement impact plates available. Primed gray.
View of Access
Size
Price
6"
$569.00
8"
579.00
10"
629.00
12"
889.00
14"
1,019.00
16"
1,329.00
18"
1,789.00
20"
2,079.00
24"
2,389.00
REPLACEMENT IMPACT PLATES
Size
Price
6", 8"
$129.00
10", 12"
189.00
14", 16"
249.00
Size
Price
18", 20"
$319.00
24"
439.00
Shown at
35°
Shown at
60°
Easy to Install
1. Cut incoming square spout to length and flange.
2. Bolt incoming spout to Adjustable Z.
3. Tighten hood bolts. Caulk hood.
4. An A-frame may be needed. Incoming spout
may need to be supported.
P.O. Box 156 · 101 Pine St.
Dickens, IA 51333
NOLIN MILLING, INC.
©2018
ADJUSTS FROM
35° TO 60°
INCOMING SPOUT RUN
ACCESS
PANEL
REPLACEMENT
IMPACT PLATE
B7
