CUSTOM GATE ORDER FORM
Step 6: Manual Control Options
18" Hand Wheel
12" Hand Wheel
8" Hand Wheel
10" Wire Rope Wheel
11" Chain Wheel
Step 7: Weather Cover
(Top and Bottom)
Premium: 7 gauge frame, 1/4" thick slide,
slide to travel on steel bearing races.
Standard Roller Gate: 10 gauge frame, 7 gauge slide,
slide to travel on 2" high density plastic rollers.
Standard Keystock Gate: 10 gauge frame,
7 gauge slide, slide to travel on keystock.
Step 4: Type of Gate
Primed Gray
Galvanized
Stainless Steel
Step 5: Finish
Nolin Standard Punched Flange.
Nolin Standard Unpunched Flange.
Custom Punched Flange (please provide punch pattern).
Step 3: Flange Specifications
Electric Options
Gear head motor drive, 1/3 h.p., totally enclosed, 115 volt.
Gear head motor drive, 1/3 h.p., totally enclosed, 230-460 volt, three phase.
Gear head motor drive, 1/3 h.p., explosion proof, 115 volt.
Gear head motor drive, 1/3 h.p., explosion proof, 230-460 volt, three phase.
Gear Head Motor Drive
Heavy duty 1/3 h.p. actuator, totally enclosed, 115 volt.
Heavy duty 1/3 h.p. actuator, totally enclosed, 230-460 volt, three phase.
Heavy duty 1/3 h.p. actuator, explosion proof, 115 volt.
Heavy duty 1/3 h.p. actuator, explosion proof, 230-460 volt, three phase.
Duff Norton Actuator Drive
Andco 115V, 0.4 IPS with internal DPDT switches,
weather proof, dust ignition proof.
Andco 460V, 0.4 IPS with internal DPDT switches,
weather proof, dust ignition proof.
Andco Potentiometer
Dial Readout for Andco
Andco Smart Card Controller
Andco Eagle Model 3100 Actuator Drive
Air operated with air cylinder and totally
enclosed 115 volt solenoid and two totally
enclosed position indicator switches.
Air operated with air cylinder and totally
enclosed 115 volt solenoid.
Air operated with air cylinder and explosion
proof 115 volt solenoid and two explosion
proof indicator switches.
Air operated with air cylinder and explosion
proof 115 volt solenoid.
Air cylinder only, mounted.
Two intrinsically safe proximity switches
for mounting on air cylinder.
Air filter with adjustable pressure regulator
shipped loose.
Air Options
Square Gate
TRAVEL
(W)
(L)
Rectangle Gate
Plate Travels the
Long Direction
TRAVEL
(W)
(L)
Rectangle Gate
Plate Travels the
Short Direction
TRAVEL
(W)
(L)
Step 1: Do you need a square or rectangle gate?
Standard Height 5-1/2" Tall
Custom Height:
For other voltages
on electric and air,
consult factory.
ID Width (W):
ID Length (L):
Step 2: Inside Flange Measurements
& Height
Step 8: Shaft Pinlock
(Patent Pending)
Padlock Not Included
©2018
This form cannot be duplicated
or reproduced in any manner
without written consent.
