ROUND SPOUTING WEIGHTS
LBS. PER FOOT
O.D. SIZE 14
GA
. 12
GA
. 10
GA
. 7
GA
.
1
/
4
" Wall
4"
3.2
4.5
5.7
7.6
5"
4.0
5.6
7.2
6"
4.8
6.8
8.6
11.6
15.3
6-5/8"
9.6
7"
7.9
10.1
8"
6.5
9.0
11.6
15.6
20.7
8-5/8"
12.1
16.9
22.4
10"
11.3
14.5
19.7
26.0
10-3/4"
15.6
21.2
28.0
12"
13.6
17.5
23.7
31.4
12-3/4"
18.6
25.2
33.4
14"
15.9
20.4
27.7
36.7
16"
18.2
23.4
31.7
42.1
0
.
8
4
"
8
1
0
.
3
5
"
0
2
0
.
4
6
"
4
2
38
2018
WWW.NOLINMILLING.COM · SALES@NOLINMILLING.COM
SQUARE SPOUTING
CAPACITY APPROXIMATIONS
SIZE
SQ. INCHES
BPH
6"
36.0
2,200
8"
64.0
4,400
10"
100.0
7,000
12"
144.0
10,000
14"
196.0
13,500
16"
256.0
17,500
18"
324.0
22,500
20"
400.0
28,000
22"
484.0
33,500
24"
576.0
40,000
30"
900.0
63,000
36"
1,296.0
90,000
ROUND SPOUTING
CAPACITY APPROXIMATIONS
DIAMETER
SQ. INCHES
BPH
6"
28.3
1,500
8"
50.3
3,500
10"
78.5
5,500
12"
113.1
8,000
14"
154.0
10,500
16"
201.1
14,000
18"
254.5
18,000
20"
314.2
22,000
22"
380.1
27,000
24"
452.3
32,000
14
GA
12
GA
10
GA
7
GA
1/4
WALL
(.0747) (.1046) (.1345) (.1793) (.2500)
SPOUTING CAPACITY CALCULATIONS FOR 8" OR LARGER SPOUT ARE BASED ON 70 BUSHELS PER
SQUARE INCH. This would require that grain be clean and spout be at 40 degrees or greater angle. This
applies only to corn, soybeans, and wheat. Wet corn should be spouted at no less than 45 degrees and capacities
do not apply. Capacities may be reduced by lining material and other factors. These are guidelines only.
Capacities may vary.
SPOUTING SPECIFICATIONS
O.D. SIZE 12
GA
. 10
GA
. 7
GA
.
1
/
4
" Wall
6"
8.6
11.0
14.6
19.2
8"
11.5
14.7
19.6
25.8
10"
14.4
18.5
24.7
32.7
12"
17.3
22.2
29.6
39.5
14"
20.2
26.0
34.6
46.3
16"
23.1
29.7
39.6
53.2
18"
26.1
33.5
44.6
60.0
20"
29.8
38.3
51.1
66.8
24"
45.7
60.9
80.5
30"
57.1
76.1
101.0
36"
68.3
91.1
121.5
SQUARE WELDED SEAM
SPOUTING WEIGHTS
LBS. PER FOOT
METAL THICKNESSES FOR
SPOUTING AND ACCESSORIES
