SYNCHRONIZED OPEN BRANCH GATE VALVE
Manually operated synchronized open branch gate valves. Branches are 10 gauge construction and at 45 degrees. Branches have premium gates bolted
to the branch outlets. Gates are chained together for synchronized operation, one gate to open - other gate to close. Price includes weather covers. Control
wheel not included in price. For round spouts, add inlet and square to rounds. Proof switches available.
A
B
C
D
12"
18-3/8"
29-1/8"
60"
14"
20-3/4"
33-1/8"
67-5/8"
16"
23"
34-7/8"
75"
18"
25-1/4"
38-1/2"
82-3/8"
20"
26-3/4"
40-3/4"
88-7/8"
24"
29-7/8"
46-1/2"
102-3/8"
A
C
B
Front
Back
Front
Back
Offset branch with synchronized electric slide gates.
Y branch with synchronized manual slide gates.
A
B
C
D
12"
21-5/8"
26-1/2"
56-1/8"
14"
22-1/8"
29-3/8"
60-7/8"
16"
26-3/8"
32-1/8"
69-3/8"
18"
28-3/4"
35"
76"
20"
30-1/4"
37-7/8"
81-3/4"
24"
32"
43-1/2"
92"
D
A
C
B
MANUALLY OPERATED
SLIDE GATE OFFSET VALVE, 7 GA
Square In
Size
Square Out
8" $1,399.00
10"
1,489.00
12"
1,569.00
14"
1,779.00
16"
1,969.00
SLIDE GATE Y VALVE, 7 GA
Square In
Size
Square Out
8" $1,389.00
10"
1,479.00
12"
1,549.00
14"
1,769.00
16"
1,949.00
18"
2,249.00
20"
2,629.00
Specs p 45
Specs p 45
SYNCHRONIZED SLIDE GATE VALVES
Manually operated synchronized slide gate valves. To be used on the bottom of hopper tanks or when material may back up into valve. Also to be used
where flowing product may have high impact. Plate slides into opposite leg for seal. Slide gate valves are 7 gauge construction and at 45 degrees. Slides
travel on 1-3/8" steel bearing races. Slide shafts are chained together for synchronized operation, one slide to open - one slide to close. Pricing includes
weather covers. Control wheel not included in price. For round spouts, add inlet and square to rounds. Proof switches available.
1/4" Expanded
5/16" Expanded
5/16" Expanded
5/16" Ceramic
Metal Backed
Metal Backed
Metal Backed
Chip Expanded
7 Ga AR
1/4" AR
Blue Urethane
Blue Urethane
Orange Urethane
Metal Backed
1/4" Ceramic
Size
10 Ga
7 Ga
1/4"
Lined
Lined
Lined
Lined
Lined
Urethane Lined
Tile Lined
12"
$1,782.00
$1,828.00
$1,897.00
$2,113.00
$2,175.00
$2,088.00
$2,163.00
$2,238.00
$2,375.00 $2,500.00
14"
1,940.00
2,019.00
2,072.00
2,345.00
2,408.00
2,320.00
2,395.00
2,495.00
2,628.00
2,753.00
16"
2,178.00
2,257.00
2,322.00
2,668.00
2,768.00
2,643.00
2,743.00
2,843.00
2,913.00
3,038.00
18"
2,359.00
2,453.00
2,597.00
2,889.00
3,014.00
2,864.00
2,989.00
3,114.00
3,297.00
3,422.00
20"
2,519.00
2,628.00
2,784.00
3,184.00
3,340.00
3,159.00
3,315.00
3,497.00
3,582.00
3,707.00
24"
3,138.00
3,294.00
3,547.00
3,944.00
4,194.00
3,919.00
4,169.00
4,357.00
4,575.00
4,700.00
ELECTRICALLY OPERATED SYNCHRONIZED OPEN BRANCH
GATE VALVE OR SYNCHRONIZED SLIDE GATE VALVE
Electric gear head motor and drive. Synchronized operation, one gate to
open - other to close. Add to any manually operated open branch gate
valve or slide gate valve price.
Gear head motor drive, 1/3 h.p., totally enclosed, 115 volt . . . . . . .add $1,489.00
Gear head motor drive, 1/3 h.p., totally enclosed, 230-460 volt
three phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .add 1,489.00
Gear head motor drive, 1/3 h.p., explosion proof, 115 volt . . . . . . .add 1,869.00
Gear head motor drive, 1/3 h.p., explosion proof, 230-460 volt
three phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .add 1,869.00
|
