EXPANDET SUPER WITH LONG EXPANSION (Technical Sheet No. 201)
DIMENSION
SCREW DIA.
DRILL
EXPANDET
BOXES / PCS.
EAN 13
CHIPB.S. WOODS.
DIA.
ARTICLE NO.
BOX
PER CARTON
PER BOX
6 X 55 MM 4,0-5,0 MM
6 MM
260655
100
20 / 2.000
5708620026558
8 X 65 MM 5,5-6,0 MM 6 MM
8 MM
260865
50
20 / 1.000
5708620026565
10 X 80 MM
8 MM
10 MM
261080
25
20 / 500
5708620026572
12 X 95 MM
10 MM
12 MM
261295
20
20 / 400
5708620026992
- See also Expandet Super on page 8
EXPANDET SUPER FRAME FIXING WITH LONG EXPANS, with zinc plated screw, torx 40 (Technical Sheet No. 202)
DIMENSION
THICKNESS
DRILL
EXPANDET
PCS. PER BOXES / PCS.
EAN 13
OF FIXTURE
DIA.
ARTICLE NO.
BOX
PER CARTON
PER BOX
10 X 100 MM
20 MM
10 MM
581100 L
50
5
5708620056357
10 X 115 MM
35 MM
10 MM
581115 L
50
5
5708620056364
10 X 135 MM
55 MM
10 MM
581135 L
50
5
5708620056371
10 X 160 MM
80 MM
10 MM
581160 L
50
5
5708620056388
- Also available with other screws, see technical sheet.
EXPANDET NYLON FRAME FIXING WITH LONG EXPANSION
10 X 200 MM
120 MM
10 MM
581200 L
50
6
5708620056395
Covercaps for torx 40 - see page 50
FastCaps, self-adhesive covercaps - see page 49
- See also Expandet Super Frame Fixing on page 9, as well as Expandet 8 mm Frame Fixing on page 8
Expandet Super with long expansion
For fixing in hollow brick, aerated concrete,
lightweight blocks and porous materials.
Expandet Super Frame Fixing
For fixing of window frames etc. in light weight
blocks, areated concrete, hollow brick and
porous materials.
Through fixing.
