Expandet Light Rosett
For fixing of lightweight objects in plasterboards,
gypsum fibre boards, chipboards and general thin
walled cavities.
Expandet Light Rosett is used in combination with
wood or chipboard screws and it tightened with
ordinary or power screwdriver. Non special tools
required. Also works in insulated cavities.
EXPANDET LIGHT ROSETT (Technical Sheet No. 102)
TYPE
SCREW
DRILL
EXPANDET
PCS. PER BOXES / PCS.
EAN 13
DIMENSION
DIAMETER
DIA.
ARTICLE NO.
BOX
PER CARTON
PER BOX
FOR ONE LAYER PLASTERBOARDS
RED, 6 X 30 MM
3,5-4,5 MM
6 MM
360630
100
20 / 2000
5708620036014
RED, 6 X 35 MM
3,5-4,5 MM
6 MM
360635
100
20 / 2000
5708620036021
BLUE, 8 X 45 MM
5,0-6,0 MM
8 MM
360845
50
20 / 1000
5708620036045
FOR TWO LAYERS PLASTERBOARDS
RED, 6 X 50 MM
3,5-4,5 MM
6 MM
360650
100
20 / 2000
5708620036038
BLUE, 8 X 55 MM
5,0-6,0 MM
8 MM
360855
50
20 / 1000
5708620036052
FastCaps, self-adhesive covercaps - see page 49
EXPANDET JET-DRIVE
®
(Technical Sheet No. 104)
TYPE
SCREW THICKNESS EXPANDET
PCS. PER BOXES / PCS.
EAN 13
DIAMETER OF FIXTURE ARTICLE NO.
BOX
PER CARTON
PER BOX
FOR ONE AND TWO LAYERS PLASTERBOARDS
Jet-Drive Metal with screw 4,5 MM
15 MM
961000
100
16 / 1600
5708620096841
Jet-Drive Metal without screw*
961100
100
16 / 1600
5708620099828
* Use chipboard screw 4,0-4,5 MM
FOR ONE LAYER PLASTERBOARDS
Jet-Drive Nylon with screw 4,5 MM
10 MM
961001
100
16 / 1600
5708620096858
EXPANDET NYLON PLASTERPLUG WITH SCREW
TYPE
THICKNESS
DRILL
EXPANDET
PCS. PER BOXES / PCS.
EAN 13
DIMENSION
OF FIXTURE
DIA.
ARTICLE NO.
BOX
PER CARTON
PER BOX
FOR ONE AND TWO LAYERS PLASTERBOARDS
4X60 MM
15 MM
10 MM
900099
50
16 / 800
5708620200392
Expandet Nylon Plasterplug
For fixing of lightweight objects in 1 and 2
layers plasterboards.
Expandet Jet-Drive
For fixing of lightweight objects like
sockets, curtain rails etc. in plasterboards
Plasterboards
2
Chipboard
screw
