DISC FOR EXPANDET ISOPLUG
DIMENSION
EXPANDET
PCS. PER
EAN 13
ARTICLE NO.
BOX
PER BOX
52 MM
868000/52
250
5708620101583
90 MM
868000/90
250
5708620101590
EXPANDET ISO-DISC 90 mm
DIMENSION
EXPANDET
PCS. PER
EAN 13
ARTICLE NO.
BOX
PER BOX
WITH 8 MM HOLE
868000/908
250
5708620100104
FOR FIXING WITH NAIL / SCREW
868000/90S
250
5708620100111
EXPANDET ISOPLUG METAL WITH 35 MM DISC
DIMENSION
THICKNESS
DRILL
EXPANDET
PCS. PER
EAN 13
OF FIXTURE
DIA.
ARTICLE NO.
BOX
PER BOX
8 X 90 MM
40- 50 MM
8 MM
868090-35
250
5708620102221
8 X 110 MM
70- 80 MM
8 MM
868110-35
250
5708620102238
8 X 140 MM
100-110 MM
8 MM
868140-35
250
5708620102245
8 X 170 MM
130-140 MM
8 MM
868170-35
250
5708620102252
8 X 200 MM
160-170 MM
8 MM
868200-35
250
5708620102269
8 X 250 MM
190-200 MM
8 MM
868250-35
200
5708620102276
8 X 300 MM
260-270 MM
8 MM
868300-35
200
5708620102306
Fire Resistance Classification: F120
EXPANDET ISO-DISC METAL - 80 MM
DIMENSION
EXPANDET
PCS. PER
EAN 13
ARTICLE NO.
BOX
PER BOX
Ø 80 MM for 868250 og 868300
868000-8
250
5708620102283
Ø 80 MM
868000-80
250
5708620102214
52 mm Disc for hard
insulating boards.
90 mm Disc for soft
insulating boards.
90 mm Expandet Iso-Disc
Use nail or screw or other suitable
fixing.
Expandet Isoplug Metal - fire-resistant assembly of
hard insulation on concrete, solid brick, limestone
and aerated concrete.
Through fixing.
For fixing of soft insulation
with Isoplug Metal.
Brick & Concrete
17
52 mm
90 mm
8 mm hole
nail/screw
