43
-
Gearboxes Series RD
RD
32 / 33
32 / 33
32 / 33
32 / 33
32
32
- - -
- - -
IEC
71
80
90 S
90 L
100
112
- - -
- - -
X / Y / Z1
140/220/121
159/238/138
176/255/149
176/280149
195/314/160
219/328/172
- - -
- - -
X1 (B5) / S
160/11.5
200/11
200/11
200/11
250/13
250/13
- - -
- - -
X1 (B14) / S
105/10.5
120/10
140/10
140/10
16011.5
160/11.5
- - -
- - -
L (RD32)
220
220[222-B14]
220[222-B14]
220[222-B14]
228[221-B14]
228[221-B14]
- - -
- - -
L (RD33)
253
253[255-B14]
253[255-B14]
253[255-B14]
- - -
- - -
- - -
- - -
Dimensions
RD32 - RD33
|
