- 8 -
Gearboxes Series RD
RS - RT
Flange Type
IEC
Kit Part No.
Elastic coupling
Flange B5
Flange B14
Type
Kit Part No.
RD 02
FM 40
IEC56
IEC63
IEC71
IEC80
K531.206.120
K531.206.140
K531.206.160
- - -
K531.206.080
K531.206.090
K531.206.105
K531.206.120
G5 ø9
G5 ø11
G5 ø14
G5 ø19
KG5.009
KG5.011
KG5.014
KG5.019
RD 03
FM 40
IEC56
IEC63
IEC71
K531.206.120
K531.206.140
K531.206.160
K531.206.080
K531.206.090
K531.206.105
G3 ø9
G3 ø11
G3 ø14
KG3.009
KG3.011
KG3.014
RD 12
FM 50
IEC56
IEC63
IEC71
IEC80
IEC90
K532.206.120
K532.206.140
K532.206.160
K532.206.200
K532.206.200
- - -
K532.206.090
K532.206.105
K532.206.120
K532.206.140
G5 ø9
G5 ø11
G5 ø14
G5 ø19
G5 ø24
KG5.009
KG5.011
KG5.014
KG5.019
KG5.024
RD 13
FM 50
IEC56
IEC63
IEC71
K532.206.120
K532.206.140
K532.206.160
- - -
K532.206.090
K532.206.105
G5 ø9
G5 ø11
G5 ø14
KG5.009
KG5.011
KG5.014
RD 22
FM 70
IEC71
IEC80
IEC90
IEC 100/112
K533.206.160
K533.206.200
K533.206.200
K533.206.250
K533.206.105
K533.206.120
K533.206.140
K533.206.160
G6 ø14
G6 ø19
G6 ø24
G6 ø28
KG6.014
KG6.019
KG6.024
KG6.028
RD 23
FM 70
IEC63
IEC71
IEC80
IEC90
K533.206.140
K533.206.160
K533.206.200
K533.206.200
- - -
K533.206.105
K533.206.120
K533.206.140
G5 ø11
G5 ø14
G5 ø19
G5 ø24
KG5.011
KG5.014
KG5.019
KG5.024
RD 32
RD 33
FM 70
IEC71
IEC80
IEC90
* IEC 100/112
K533.206.160
K533.206.200
K533.206.200
K533.206.250
K533.206.105
K533.206.120
K533.206.140
K533.206.160
G6 ø14
G6 ø19
G6 ø24
G6 ø28
KG6.014
KG6.019
KG6.024
KG6.028
RD 42
RD 43
FM 85
IEC71
IEC80
IEC90
** IEC 100/112
K534.206.160
K534.206.200
K534.206.200
K534.206.250
- - -
K534.206.120
K534.206.140
K534.206.160
G6 ø14
G6 ø19
G6 ø24
G6 ø28
KG6.014
KG6.019
KG6.024
KG6.028
RD 52
FM 130
&
FM 150
IEC 80
IEC 90
IEC 100/112
IEC 132
IEC 160
IEC 180
K536.206.200
K536.206.200
K536.206.250
K537.206.300
K565.206.350
K565.206.350
- - -
- - -
- - -
K536.206.200
K536.206.250
- - -
***
GS8 ø19
***
GS8 ø24
***
GS8 ø28
***
GS8 ø38
***
GS8 ø42
***
GS8 ø48
KGS8.019
KGS8.024
KGS8.028
KGS8.038
KGS8.042
KGS8.048
RD 53
FM 130
IEC 80
IEC 90
IEC 100/112
K536.206.200
K536.206.200
K536.206.250
- - -
- - -
- - -
***
GS8 ø19
***
GS8 ø24
***
GS8 ø28
KGS8.019
KGS8.024
KGS8.028
RD 62
FM 130
&
FM 150
IEC 80
IEC 90
IEC 100/112
IEC 132
IEC 160
IEC 180
K536.206.200
K536.206.200
K536.206.250
K537.206.300
K565.206.350
K565.206.350
- - -
- - -
- - -
K536.206.200
K536.206.250
- - -
***
GS8 ø19
***
GS8 ø24
***
GS8 ø28
***
GS8 ø38
***
GS8 ø42
***
GS8 ø48
KGS8.019
KGS8.024
KGS8.028
KGS8.038
KGS8.042
KGS8.048
RD 63
FM 130
&
FM 150
IEC 80
IEC 90
IEC 100/112
IEC 132
K536.206.200
K536.206.200
K536.206.250
K537.206.300
- - -
- - -
- - -
K536.206.200
***
GS8 ø19
***
GS8 ø24
***
GS8 ø28
***
GS8 ø38
KGS8.019
KGS8.024
KGS8.028
KGS8.038
*
- IEC100/112: not for RD33
** - IEC112: not for RD43
***
- Coupling GS8: steel and key fit
IEC - Flanges and Elastic coupling selection
