Gearboxes Series RD
Flanges and Elastic coupling selection - NEMA
RS - RT
Flange Type
NEMA
Kit Part No.
Elastic coupling
Type
Kit Part No.
RD 02
FM 40
48 C
56 C
K531.227.N48
K531.227.N56
G5 ø 1/2"
G5 ø 5/8"
KG5.N48
KG5.N56
RD 03
42 C
48 C
K531.227.N48
K531.227.N48
G3 ø 3/8"
G3 ø 1/2"
KG3.N42
KG3.N48
RD 12
FM 50
56 C
140 TC
K532.227.N56
K532.227.N56
G5 ø 5/8"
G5 ø 7/8"
KG5.N56
KG5.N140
RD 13
56 C
K532.227.N56
G5 ø 5/8"
KG5.N56
RD 22
FM 70
56 C
140 C
180 C
K533.227.N56
K533.227.N56
K533.227.N180
G6 ø 5/8"
G6 ø 7/8"
G6 ø 1-1/8"
KG6.N56
KG6.N140
KG6.N180
RD 23
56 C
140 C
K533.227.N56
K533.227.N56
G5 ø 5/8"
G5 ø 7/8"
KG5.N56
KG5.N140
RD 32
FM 70
56 C
140 TC
180 TC
K533.227.N56
K533.227.N56
K533.227.N180
G6 ø 5/8"
G6 ø 7/8"
G6 ø 1-1/8"
KG6.N56
KG6.N140
KG6.N180
RD 33
56 C
140 TC
K533.227.N56
K533.227.N56
G6 ø 5/8"
G6 ø 7/8"
KG6.N56
KG6.N140
RD 42
FM 85
56 C
140 TC
180 TC
K534.227.N56
K534.227.N56
K534.227.N180
G6 ø 5/8"
G6 ø 7/8"
G6 ø 1-1/8"
KG6.N56
KG6.N140
KG6.N180
RD 43
56 C
140 TC
180 TC
K534.227.N56
K534.227.N56
K534.227.N180
G6 ø 5/8"
G6 ø 7/8"
G6 ø 1-1/8"
KG6.N56
KG6.N140
KG6.N180
RD 52
FM 150
56 C
140 TC
180 TC
210 TC
K537.227.N56
K537.227.N56
K537.227.N180
K537.227.N180
* GS8 ø 5/8"
* GS8 ø 7/8"
* GS8 ø 1-1/8"
* GS8 ø 1-3/8"
KGS8.N56
KGS8.N140
KGS8.N180
KGS8.N210
RD 53
56 C
140 TC
180 TC
210 TC
K537.227.N56
K537.227.N56
K537.227.N180
K537.227.N180
* GS8 ø 5/8"
* GS8 ø 7/8"
* GS8 ø1-1/8"
* GS8 ø 1-3/8"
KGS8.N56
KGS8.N140
KGS8.N180
KGS8.N210
RD 62
56 C
140 TC
180 TC
210 TC
K537.227.N56
K537.227.N56
K537.227.N180
K537.227.N210
* GS8 ø 5/8"
* GS8 ø 7/8"
* GS8 ø 1-1/8"
* GS8 ø 1-3/8"
KGS8.N56
KGS8.N140
KGS8.N180
KGS8.N210
RD 63
56 C
140 TC
180 TC
210 TC
K537.227.N56
K537.227.N56
K537.227.N180
K537.227.N210
* GS8 ø 5/8"
* GS8 ø 7/8"
* GS8 ø 1-1/8"
* GS8 ø 1-3/8"
KGS8.N56
KGS8.N140
KGS8.N180
KGS8.N210
**
- Coupling GS8: steel and key fit
FM 150
