- 42 -
Gearboxes Series RD
RD
22 / 23
22 / 23
22 / 23
22 / 23
22 / 23
22
22
- - -
IEC
63
71
80
90 S
90 L
100
112
- - -
X / Y / Z1
123/185/110
140/220/121
159/238/138
176/255/149
176/280/149
195/314/160
219/328/172
- - -
X1 (B5) / S
140/10
160/11.5
200/11
200/11
200/11
250/13
250/13
- - -
X1 (B14) / S
- - -
105/10.5
120/10
140/10
140/10
160/11.5
160/11.5
- - -
L (RD22)
192
190
190[192-B14]
190[192-B14]
190[192-B14]
191[190-B14]
191[190-B14]
- - -
L (RD23)
240
208
208[210-B14]
208[210-B14]
208[210-B14]
- - -
- - -
- - -
Dimensions
RD22 - RD23
|
