Smart
LED
Lighting
· High CRI · High Lumen Output ·
· Self Ballasted · Dimmable ·
· UL Approved · Energy Star Certified ·
· 50,000 Hours (L
70
B
50
) ·
· Low Profile - Only 3-inch Thick ·
· Less than 2-inch Thick with "Remote LED Driver" ·
Model
Product
Size
Power
Flux
Eqv.
DL6-9W-27K-120V-DULES
LED Downlight 6-inch 9W E26 2700K
120V 120° Beam Angle DIM UL+ES
Ø7" x 3"
Ø180x76mm
9W
650 lm
60W ~
75W
DL6-13W-30K-120V-DULES
LED Downlight 6-inch 13W E26 3000K
120V 120° Beam Angle DIM UL+ES
Ø7" x 3"
Ø180x76mm
13W
940 lm
75W ~
100W
DL6-15W-40K-120V-DULES
LED Downlight 6-inch 15W E26 4000K
120V 120° Beam Angle DIM UL+ES
Ø7" x 3"
Ø180x76mm
15W
1,130 lm
120W ~
150W
· 120Vac ~50/60Hz · P.F. > 0.9 · Medium (E26) Lamp Base · ~75lm/W · CRI 80 ·
() "Eqv." ÷ Comparable Equivalence to Incandescent Lamps Wattage
Use 27K for 2,700K, 30K for 3,000K, 40K for 4,000K, 50K for 5,000K
