Smart
LED
Lighting
Direct Replacement for High Power
Metal Halide Lamps in High Bay Light Fixtures
()
· Rated Life 50,000 Hours
()
· Directive 30~120° Beam Angle
()
·
· High Power Factor · Self Ballasted · Bright · High CRI · High Lumen Output ·
Model
Product
Size
Power
Flux
Equivalent
HBL-60W-IP65-55K-E39
(IP65 ÷ Waterproof)
Hi-Bay LED Lamp 60W
5500K E39 277Vac IP65 120°
Ø 10¾ (dia.)
L 5½" (MOL)
69W
Max.
6,800 Lumen
250W
MH or HPS
HBL-100W-55K-E39-60d
(IP22 ÷ Non Waterproof)
Hi-Bay LED Lamp 100W
5500K E39 277Vac 60°
Ø 9½ (dia.)
L 5" (MOL)
100W
Max.
10,000 Lumen
360/400W
MH or HPS
HBL-120W-55K-E39-60d
(IP22 ÷ Non Waterproof)
Hi-Bay LED Lamp 120W
5500K E39 277Vac 60°
Ø 9½ (dia.)
L 5¾" (MOL)
120W
Max.
11,500 Lumen
400W
MH or HPS
· 100-277Vac ~50/60Hz · PF > 0.9 · Medium (E26/E27) or Mogul (E39/E40) Lamp Base ·
· ~95 lm/W · CRI 75 · CCT 3,000K or 5,500K ±10% ·
()
Rated Life 50,000 Hrs. (L
70
B
50
) at T
[A]
45°C Max. ·
IP22 ÷ Non-Waterproof & IP65 ÷ Waterproof versions
Design registration & Patent pending
Cree® XLamp® XT-E LEDs
() Available in 30° - 45° - 60° Beam Angle Options
() Requires Ballast Removal
