Smart
LED
Lighting
Model
Product
Size (
Dia.xMOL)
Power
Flux
Equivalent
CCL-10W12-55K-E26
10W Compact Cluster LED Bulb
Ø2¾"x5" (Ø70x128mm)
11W
1,100 lm
50W MH/HPS
CCL-15W12-55K-E26
15W Compact Cluster LED Bulb
Ø2¾"x5" (Ø70x128mm)
16W
1,600 lm
50/70W MH/HPS
CCL-20W12-55K-E26
20W Compact Cluster LED Bulb Ø2¾"x6¼" (Ø70x160mm)
22W
2,100 lm
70/100W MH/HPS
CCL-25W12-55K-E26
25W Compact Cluster LED Bulb Ø2¾"x7" (Ø70x181mm)
26W
2,600 lm
100W MH/HPS
CCL-30W12-55K-E26
30W Compact Cluster LED Bulb Ø2¾"x7" (Ø70x181mm)
30W
3,000 lm
150/175W MH/HPS
· 100-277Vac ~50/60Hz · P.F. > 0.95 · Med. (E26/E27) or Mogul (E39/E40) Lamp Base · ~100lm/W · Color Temp. (CCT) ±10% ·
·
()
Rated Life 50,000 Hrs. (L
70
B
50
) at T
[A]
25°C Max. · CRI > 70 ·
Listed to UL Standard 1598c & UL 1993
· Rated Life 50,000 Hours
()
·
· High Power Factor · Self Ballasted ·
· Bright · High CRI · High Lumen Output ·
· Built-in Surge Suppressors & Transient Protection ·
