Smart
LED
Lighting
· Bright · High CRI · High Lumen Output ·
· High Power Factor · Self Ballasted ·
· Rated Life 50,000 Hours
()
·
· Built-in Surge Suppressors & Protection ·
· G24 Universal Base fits G24d1-3, G24q1-3, GX24q1-4 ·
· Simple Installation · High Lumen per Watt · Rugged Design ·
Model
Product
Size
Power
Flux
Eqv.
CFL-10W12S-41K-G24
10W G24 Cluster LED Bulb SMD 360°
18W 4Pin CFL Replacement
Ø70x123mm
Ø2¾"x4¾"
10W
1,100 lm
75W
CFL18
CFL-15W12S-41K-G24
15W G24 Cluster LED Bulb SMD 360°
26W 4Pin CFL Replacement
Ø70x123mm
Ø2¾"x4¾"
16W
1,600 lm
100W
CFL26
CFL-20W12S-41K-G24
20W G24 Cluster LED Bulb SMD 360°
32W 4Pin CFL Replacement
Ø70x153mm
Ø2¾"x6"
22W
2,100 lm
125W
CFL32
CFL-25W12S-41K-G24
25W G24 Cluster LED Bulb SMD 360°
42W 4Pin CFL Replacement
Ø70x153mm
Ø2¾"x6"
25W
2,600 lm
150W
CFL42
· 100-277Vac ~50/60Hz · P.F. > 0.95 · G24 Universal Lamp Base · 85~110lm/W · CRI 80 ·
· CCT 4,100K ±10% · "Eqv." ÷ Equivalence to Incandescent Lamps ·
()
Rated Life 50,000 Hrs. (L
70
B
50
) at T
[A]
45°C Max. ·
