T0265-100 PROBE 100
The Probe 100 is the most advanced automotive circuit tester to date, easy to use and an affordable must-have for every
automotive technician looking for a fast and accurate solution to reduce diagnostic time in all 6- to 30-volt vehicle electrical
systems.
Advantages :
· Onceconnectedtothevehicle'sbattery,thetechnicianalwayshasagoodreferencevoltageandground,whendiagnosingan
electrical circuit.
· In comparison to a normal multi-meter, where one needs 2 hands to measure power and ground, the Probe 100 allows one-
hand operation and makes it easier to measure power, detect voltage drops and bad grounds immediately, perform polarity
checks and continuity tests.
· With a flip of the power switch, you have an instant hot/ground lead to activate
electrical components like cooling fans, relays, power window motors, etc. of or off the vehicle.
The high-contrast colour TFT display with 7mm high read-out allows you to read voltage, current and resistance. When
testing component signals, the scope function visualizes the signal, with the added benefit of maximum/minimum volts,
frequency and duty cycle.
Audible and visible polarity indicator and 2 integrated LED work lights, to illuminate your testing area.
6 meter (extendable) lead connects to the vehicle's battery (12V to 24V) to reach all areas of the vehicle.
Includes : Probe 100, 6 meter extension cable, probe tip, battery hook-up clips, cigarette lighter adapter and user manual.
Specification :
· DC Voltage : 0-65V
· Frequency : 0 10 kHz
· Duty cycle : 1 99%
· Resistance:02MOhm
· Resettable circuit breaker : 10A
Probe 100
T0265-100
DC VOLTAGE
SPANNUNG
TENSION C.C.
AC VOLTAGE
SPANNUNG
TENSION C.A.
RESISTANCE
WIEDERSTAND
