Fastening with two bar clips | Operator switch with
emergency stop function | Guide roller with load hook | Motor
with thermal switch | Automatic load securing brake | Load
hook with safety catch | Automatic limit cut-out for rolling out
4 0 0 6 8 2 5 5 3 9 7 7 6
230 V ~ 50 Hz
1600 W
S3 25% 10 min
max. 5.7 m
max. 999 kg
max. 11.5 m
max. 500 kg
29.8 / 33.3 kg
1
570 x 255 x 340 mm
Article number
22.557.15
BT-EH 1000
ELECTRIC HOIST
SWING ARM GT-SA 1200 FOR
HOISTS
Length 1100 mm | With reach of 750 mm max. load
600 kg | With reach of 1100 mm max. load 300 kg
4 0 0 6 8 2 5 5 4 0 0 1 7
Artikelnummer /
Article number
22.553.98
1
Article number
22.553.98
BT-CH 1000
CHAIN HOIST
Closed metal housing | Load hook with safety catch |
Long operator chain | Low design
4 0 0 6 8 2 5 5 3 9 7 3 8
1000 kg
2.5 m
8.5 / 9.4 kg
1
250 x 180 x 160 mm
Article number
22.501.02
BT-HT 100
HAND TRUCK
Aluminium / steel frame | Fully retractable rubber
wheels | Folding aluminium base plate | Pull-out handle |
Rubber-coated handle | Lock for extending handle
4 0 0 6 8 2 5 5 6 4 0 8 2
3.7 / 4.4 kg
2
700 x 480 x 65 mm
Article number
22.601.13
max. 100 kg
Folded
700 x 480 x 65 mm
Unfolded
985 x 480 x 420 mm
kg
BT-HT 90
HAND TRUCK
Lock for extending handle | Pull-out handle |
Aluminium frame | Folding base plate | Rubber feet with
metal bush
4 0 0 6 8 2 5 5 4 0 0 5 5
5.6 / 5.8 kg
1
710 x 380 x 190 mm
Article number
22.601.12
max. 90 kg
Folded
710 x 380 x 190 mm
Unfolded
1070 x 350 x 410 mm
kg
BT-PT 2500
PALLET TRUCK
Selector lever for lift / neutral / lower | Safety
handle with loop grip | Automatic return of the drawbar |
Ball-bearing and PU-coated steering wheels and double
load-bearing rollers
4 0 0 6 8 2 5 5 6 3 2 2 1
2500 kg
1150 mm
85 mm /
200 mm
550 mm
Ø 180 mm
Ø 80 mm
70.0 / 75.0 kg
1
2100 x 560 x 740 mm
Article number
20.225.25
kg
TOOL AND GEAR WAGGON
BT-TW 150
Strong sheet steel frame | Non-slip work surface |
7 ball-bearing drawers (fully extendable thanks to telescopic
rails) | 4 large easy-running wheels (of which 2 are steer-
able with locking brake) | Lockable
4 0 0 6 8 2 5 5 6 4 1 3 6
max. 150 kg
54.0 / 57.5 kg
1
730 x 800 x 505 mm
Article number
45.101.50
4 x 45 mm
2 x 100 mm
1 x 200 mm
685 mm (Width) 875 mm (Height)
460 mm (Depth)
kg
DE: price/performance "Very Good"
