Weight net / gross
Packaging unit
Packing dimensions
BT-UP 470
UNIVERSAL PANEL SAW
Aluminium table with cross stop | Angle setting in
increments of one degree from 45°, 30°, 20°, 15°, -10°
to 10° | Parallel stop for longitudinal cuts | With clamping
device, sawdust bag and push stick
4 0 0 6 8 2 5 5 6 6 5 7 4
230 V ~ 50 Hz
Ø 127 x Ø 17
860 W / S1 n
0
= 11000 min
-1
7.2 / 8.7 kg
1
690 x 375 x 205 mm
Article number
43.074.00
max. 18 mm
HW / TCT
t = 14
DE: price/performance
"Good Very Good"
BT-SB 200
BAND SAW
Saw bench angle can be infi nitely adjusted from
0° to 45° | Push stick | Saw blade guide infi nitely height-
adjustable | Adjustable parallel stop with eccentric clamp |
Dust extractor
4 0 0 6 8 2 5 5 4 0 2 1 5
230 V ~ 50 Hz
250 W
S2 15 min
n
0
= 6000 min
-1
13.2 / 17.6 kg
1
350 x 270 x 720 mm
Article number
43.080.22
90°: 80 mm
45°: 45 mm
200 mm
300 x 300 mm
1400 x 6.4 mm,
6 Z / 25 mm
0° - 45 °
BT-SS 405 E
SCROLL SAW
Chip blower | Electronic blade speed control | Zero
voltage switch | Connection for dust extractor | Adapter for
coping saw blades
4 0 0 6 8 2 5 5 4 0 0 3 1
230 V ~ 50 Hz
127 mm
406 mm
410 x 253 mm
230 W
S2 5 min
n
0
= 400 -
1600 min
-1
10.3 / 11.8 kg
1
640 x 310 x 333 mm
Article number
43.090.18
Electronic
BT-WW 1000
WOODWORKING LATHE
Strong guide frame | Tailstock with self-centering
live spindle tip | Workpiece support | Front end driver ring |
Face plate Ø 143 mm | Long-lasting V-belt drive which can
be adjusted to 4 settings
4 0 0 6 8 2 5 5 4 0 6 1 1
230 V ~ 50 Hz
550 W
S2 30 min
27.5 / 38.0 kg
1
1500 x 230 x 260 mm
Article number
43.121.02
l
max
= 1000 mm
Ø
max
= 356 mm
n
0
= 810/1180/
1700/2480 min
-1
BT-SP 1300
STATIONARY PLANE
Aluminium thicknessing table | Parallel stop in-
fi nitely adjustable from 0° to +45° | Pull-out workpiece
support | Tipping guard | Zero voltage switch | Chip ex-
traction Ø 100 / 36 mm
4 0 0 6 8 2 5 5 4 1 4 2 7
23.5 / 27.5 kg
1
731 x 390 x 410 mm
Article number
44.199.41
n
0
= 9000 min
-1
max. 3 mm
max. 2 mm
8 m/min.
max. 100 mm max. 152 mm
230 V ~ 50 Hz 860 W / S1
BT-US 400
BELT AND DISK SANDER
Belt grinding device | Support table (can be angled
from 0° to 45°) | Cross stop (-60° to +60°) | Disc grinder
with quick-fi t fastening system | 4 rubber feet to ensure that
the machine stands securely
4 0 0 6 8 2 5 5 4 1 5 5 7
230 V ~ 50 Hz
Ø 150
375 W
S2 30 min
n
0
= 1450 min
-1
15.6 / 18.0 kg
1
500 x 300 x 260 mm
Article number
44.192.53
100 x 915 mm
18
