Weight net / gross
Packaging unit
Packing dimensions
BT-ML 300
METAL LATHE
Counter-clockwise/clockwise selector switch | In-
ternally and externally stepped clamp jaws | Centering pin |
Different feed speeds | Automatic feed | Infi nitely adjustable
speed control
4 0 0 6 8 2 5 5 4 1 5 3 3
230 V ~ 50 Hz
350 W
S3 50%
0 - 1100 min
-1
0 - 2500 min
-1
37.0 / 43.0 kg
1
770 x 330 x 330 mm
Article number
45.050.04
l
max
300 mm
max. Ø 70 mm Ø 25 - 70 mm
max. Ø 70 mm
BT-MB 550 U
METAL BAND SAW
Base frame with wheels and handle | Clamping
device for workpieces | Automatic limit cut-out | Adjustable
belt guides | Mitre cuts: 0° to 45° | Zero voltage switch |
Suitable for dry cutting
4 0 0 6 8 2 5 5 4 1 4 4 1
230 V ~ 50 Hz 550 W (S1)
70.4 / 76.8 kg
1
1007 x 382 x 385 mm
Article number
45.042.02
I: 1640 mm
v: 20/30
50 m/min
n
0
= 1470 min
-1
90°: Ø 110 mm
100 x 130 mm
45°: Ø 65 mm
85 x 60 mm
BT-MC 355
METAL CUTTING-OFF MACHINE
Clamping device for workpieces | Cutting wheel |
Machine vise can be tilted to 45° (mitre cuts) | Suitable for
dry cutting | Spindle lock | Thermal switch
4 0 0 6 8 2 5 5 4 1 5 2 6
230 V ~ 50 Hz
2550 W
n
0
= 3800 min
-1
17.5 / 19.5 kg
1
570 x 480 x 340 mm
Article number
45.031.24
Ø 355 x Ø 25.4
x 3.2 mm
90° /
105 x 45 mm
45°
85 x 45 mm
BT-MR 550
METAL ROUTING MACHINE
Wheel selector for fi ne feed | Compound table with
cross slide and longitudinal slide | Depth stop | Electronic
speed control | Two speed ranges (L/H)
4 0 0 6 8 2 5 5 4 1 5 4 0
230 V ~ 50 Hz
220 mm | 100 mm
| 280 mm
550 W
S3 50%
0 - 1100 min
-1
0 - 2500 min
-1
50.0 / 68.0 kg
1
540 x 500 x 760 mm
Article number
42.530.02
max. 13 mm
MK3
-45° to +45°
BT-WD 150/200
WET-DRY GRINDER
Adjustable tool support | Sturdy worm gearing for
the wet grinding disc | Slow-speed, fi ne-grained wet grind-
ing disc | Corrosion-resistant water bath container | RCD
plug for protection of life and health
4 0 0 6 8 2 5 5 3 7 7 0 3
230 V ~ 50 Hz
n
0
= 134 min
-1
250 W
S2 30 min
n
0
= 2950 min
-1
9.8 / 10.3 kg
1
420 x 260 x 270 mm
Article number
44.172.15
Trockenscheibe
Ø 150 x Ø 20
Ø 200 x Ø 40
VISE FOR BENCH DRILLS
Max. clamping range 75 mm
4 0 0 6 8 2 5 4 2 1 0 0 2
1
Article number
42.257.06
REVERSIBLE PLATE CUTTER FOR
BT-MR 550
Ø 30 mm | Cutter 2 pieces
4 0 0 6 8 2 5 5 5 6 8 5 8
1
Article number
42.530.23
CARBIDE METAL REVERSIBLE
CUTTING PLATES FOR BT-MR 550
For indexable insert routing cutter | 2 pieces |
Length 16 mm
4 0 0 6 8 2 5 5 5 6 8 6 5
2
Article number
42.530.24
HIGH SPEED VISE FOR
BT-MR 550
Max. clamping range 75 mm | Width 100 mm |
With quick adjust
4 0 0 6 8 2 5 5 5 6 8 2 7
1
Article number
42.530.20
SCHLEIFPAPIER-SET FÜR BT-MG 180/1
SET OF VELCRO GRINDING / SANDING
PAPERS FOR BT-MG 180/1
COLLET CHUCK KIT FOR
BT-MR 550
9 pieces | Taper MK 3 |
Inner diameter: Ø 4 / 6 / 8 / 10 / 12 / 14 / 16
4 0 0 6 8 2 5 5 5 6 8 3 4
Artikelnummer /
Article number
42.580.85
1
Article number
42.530.21
SCHLEIFPAPIER-SET FÜR BT-MG 180/1
SET OF VELCRO GRINDING / SANDING
PAPERS FOR BT-MG 180/1
CLAMP CLAW KIT FOR
BT-MR 550
42 pieces | Clamping claws | Support trestles |
T-sliding blocks | Stud bolts M10
4 0 0 6 8 2 5 5 5 6 8 4 1
Artikelnummer /
Article number
42.580.85
1
Article number
42.530.22
