2016 Beaverstate Dental Equipment and Supplies Catalog Page 93

800.237.2303

503.538.8756

503.538.2845 Fax

www.beaverstatedental.com

Horizontal Folding Arm

Part No. 105-026, 24" wall mount .........................................$235.00

Part No. 105-027, 24" post mount .......................................$235.00

Part No. 105-028, 32" wall mount .........................................$245.00

Part No. 105-029, 32" post mount .......................................$245.00

3 position holder bar with 3 handpiece holders

2" dia. post mount or wall mount

24" or 32" horizontal reach

Folding Arm Section Only

Part No. 105-040, 6" section ......................................................$50.00

Part No. 105-039, 8" section ......................................................$54.00

Part No. 105-042, 12" section ...................................................$55.00

Part No. 105-043, 16" section ...................................................$60.00

1/2" dia. pin mounts to a 2" dia. post mount clamp

or wall mount

1/2" I.D. female end with bronze bushing

Holder Bar with Holders

Part No. 105-017, 3 position.......................................................$65.00

1 HVE holder

1 saliva ejector holder

1 syringe holder

1/2" dia. pin mounts to horizontal folding arm

Part No. 105-034, 4 position.......................................................$70.00

2 HVE holders

1 saliva ejector holder

1 syringe holder

1/2" dia. pin mounts to horizontal folding arm

Holder Bar with 1/2" dia. Pin

Part No. 105-008, 3 position.......................................................$32.00

Part No. 105-009, 4 position.......................................................$34.00

Mounting holes for holders 141-006 and 141-038

1/2" dia. pin mounts to horizontal folding arm

1/2" dia. Pivot Mount

Part No. 103-065 ...............................................................................$35.00

Used to mount A-200 and A-400 series units to

horizontal folding arms

2" aluminum mount with 1/2" dia. pin

Includes mounting screws

3 Position

4 Position

Washer for Pin with 1/2" dia.

Part No. 003-006 .....................................................................................$.65

Used with horizontal folding arms

105-017

Bracket for 1/2" dia. Pin Mount

Part No. 105-060 ...............................................................................$37.00

1/2" Pin protrudes from bottom of mount

Used with horizontal folding arms

Includes mounting screws

105-034

Arms and

Brackets
