Features of Aerolight
Post Mt. Ceiling Mt.
Exclusive ball and socket pivot allows unrestricted multi axis positioning
Unique adjustable pivot tension without tools
Sharply defined rectangular light pattern, 3 1/2" x 4 1/2" at 29"
4500
o
low setting to 5100
o
high setting, Kelvin temperature
(ideal for shade matching and examination)
Easy reach ON/OFF intensity switch
2-way switch for low
(18,000 LUX)
and high
(23,000 LUX)
intensity
Glass reflector with dichroic coating, filters out infrared rays, providing cool light
26V, 100 Watt halogen bulb with single filament
Easy bulb replacement without tools
Easy open safety shield allows for cleaning
110 Volt
Slim profile minimizes heat
Accommodates ceiling heights from 8' to 10' (see note below)
Options
Part Number Price
Flat Ceiling Cover Plate, 8" dia. (in lieu of domed cover)
102-160
n/c
NOTES:
Aerolight bulb is specifically designed for use with the Aerolight for 1000 hour rating.
When ordering Aerolight in Ceiling Mount configuration, please provide
ceiling height measured from floor to hard mounting surface.
For total mounting bracket concealment in drop-ceiling configuration,
allow 7 1/4" inch depth between hard surface mount to drop ceiling.
Aerolight is shipped with domed cover (102-165) to completely conceal mounting bracket.
800.237.2303
503.538.8756
503.538.2845 Fax
www.beaverstatedental.com
79
