Toftejorg SaniMicro
·
Flow/Pressure: 1.5m³/h 3.5m³/h @ 1 3 bar
·
Vessel Size: 0.05m³ 1m
3
·
Impact/Wetting Radius: 0.6m 2.5m
·
Application: IBC's, Mixing Vessels, Process
Vessel, Small Vessels, Vent Pipes.
Toftejorg SaniMagnum
·
Flow/Pressure: 5m³/h 18m³/h @ 1 3 bar
·
Vessel Size: 5m³ 50m
3
·
Impact/Wetting Radius: 2m 3m
·
Application: Mixing and Storage Vessels,
Bright Beer Tanks, Milk Silo's.
Standard Spray Balls
Spherical Spray balls
available in standard
360
o
and 180
o
upwards,
downwards and side spray
patterns.
Available in clip on, threaded
or weld on connection.
Toftejorg SaniMidget Retractor
·
Flow/Pressure: 4.8m³/h 9.5m³/h @ 2 5 bar
·
Impact/Wetting Radius: 1.7m 3.5m
·
Application: Dryer Systems, Duct Work,
Process Vessels,
Toftejorg SaniMagnum SB
·
Flow/Pressure: 9m³/h 15m³/h @ 1 3 bar
·
Vessel Size: 68m³ 227m³
·
Impact/Wetting Radius: 2.4m 4.5m
·
Application: Process Vessels, Bright Beer
Tanks and Milk Tanks.
·
Maintainable, 3A Approval, Slide Bearing Design
Toftejorg SaniMidget
·
Flow/Pressure: 4 m³/h 6m³ @ 1 3 bar
·
Vessel Size: 0.1m³ 10m
3
·
Impact/Wetting Radius: 1m 3m
·
Application: IBC's, Mixing Vessels, Process
Vessels, Small Vessels, Vent Pipes.
Toftejorg SaniMega
·
Flow/Pressure: 20m³/h 29m³/h @ 2 4 bar
·
Vessel Size: 50m³ 350m³
·
Impact/Wetting Radius: 3m
·
Application: Large Dairy Silo's
Large Storage Vessels.
Toftejorg SaniMidget SB
·
Flow/Pressure: 7.25m³/h @ 1 3 bar
·
Vessel Size: 7.5m³ 22m³
·
Impact/Wetting Radius: 1.4m 3m
·
Application: IBC's, Mixing Vessels,
·
Process Vessels, Small Vessels, Vent Pipes
·
Maintainable, 3A Approval, Slide Bearing Design
Toftejorg SaniMega SB
·
Flow/Pressure: 20m³/h 29m³/h @ 2 4 bar
·
Vessel Size: 50m³ 350m³
·
Impact/Wetting Radius: 2.3m 6m
·
Application: Large Dairy Silo's, Large
Storage Vessels.
·
Maintainable, 3A Approval, Slide Bearing Design
Dip Pipe Assembles
Bespoke fabrications
including Adaptors,
Connections, Dip Pipe
Assemblies, Removable
Lances, Spray Balls,
Manifolds
Toftejorg MultiJet 25
·
Flow/Pressure: 5m³/h 15m³ @3 8 bar
·
Vessel Size: 15m³ 150 m³
·
Impact/Wetting Radius: 4m 14m
·
Bead Blasted Finish
·
Processing, Storage and Transportation
Tanks and Vessels
Toftejorg TZ-89
·
Flow/Pressure: 1.2m³/h 4m³/h @2 7 bar
·
Vessel Size: 0.5m³ 50m³
·
Impact/Wetting Radius: 2.5m 7m
·
Application: Sanitary, IBC Cleaning, Smaller
Mixing Vessels, Portable Vessel Cleaning.
Toftejorg SaniJet 25
·
Flow/Pressure: 5m³/h 15m³/h @3 8 bar
·
Vessel Size: .15m³ 150m³
·
Impact/Wetting Radius: 4m 14m
·
Application: Sanitary. Ultimate Rotary Jet
Head for the Large Pharmaceutical Vessel.
Toftejorg TJ20G
·
Flow/Pressure: 5m³/h 15m³/h @3 8 bar
·
Vessel Size: 15m³ 150m³
·
Impact/Wetting Radius: 4m 14m
·
Application: Sanitary, Personal Care, Brewing
Distilling, Dairy
Toftejorg TZ-74
·
Flow/Pressure: 11m³/h 32.5m³/h @3 12 bar
·
Vessel Size: 50m³ 500m³
·
Impact/Wetting Radius: 4m 17m
·
Application: Sanitary, Brewery Fermenters,
Brewhouse Vessels/Mash Tun
Toftejorg SaniJet 20
·
Flow/Pressure: 1.6m³/h 6m³/h @3 18 bar
·
Vessel Size: 0.5m³ 30m³
·
Impact/Wetting Radius: 1.5m 4m
·
Application: Sanitary. Ultimate Low Volume
Rotary Jet Head for the Pharmaceutical Industry.
Toftejorg TZ-79
·
Flow/Pressure: 17m³/h 51m³/h @3 12 bar
·
Vessel Size: 250m³ 1250m³
·
Impact/Wetting Radius: 5m 26m
·
Application: Large Brewery Fermenters.
Large Storage Vessels
Toftejorg MultiJet 40
·
Flow/Pressure: 10m³/h 30m³/h @3 12 bar
·
Vessel Size: 50m³ 500m³
·
Impact/Wetting Radius: 4m 17m
·
Bead Blasted Finish
·
Large Storage, Mash Tun, Biofuel, Fermenters
Weighing System
Pressure Gauge
Rotacheck
Level Switch
Flow Transmitter
Manway
Potentiometric
Level Transmitter
Tank Feet
ToFTeJoRG RoTARY CLeANING HeAD
ToFTeJoRG RoTARY JeT HeADS
INSTRUMeNTATIoN AND ACCeSSoRIeS
FIXeD SPRAY BALLS AND DIP PIPe ASSeMBLIeS
Static Spray Balls
Thick Walled or Target
drilled thick wall variants,
drilled to specifically suit the
application and the available
flow/pressure.
Available in clip on, threaded
or weld on connection.
Mushroom Spray Balls
Mushroom Balls allow for
an increased number of
upward facing holes to be
drilled. Target drilled to suit
individual applications.
Available in clip on, threaded
or weld on connection.
