he Generator and Storage Cabinet provides hot lab radiation
protection without hampering the elution process. The left
drawer accommodates top or side loading generators. In addition
to the .5" or 1" lead shielding in front, the drawer has .25" lead
shielding on the remaining three sides and bottom. A removable
drawer top allows generator replacement. Trap doors on the top
and sides of this drawer provide safe access to the generator. The
cabinet has two shielded compartments on the right side for storing
decaying generators prior to disposal.
SPECIFICATIONS:
Dimensions: 36.5" w x 24" depth x 36.5" h (92.7 x 61 x 92.7 cm)
Lead Shielding:
Cabinet:
.5" (1.3 cm) or 1" (2.5 cm) thick on all six sides
Drawer: .25" thick (.64 cm) on five sides
Dividers:
.5" thick (1.3 cm)
Drawer Dimensions: I.D.: 15.5" w x 11.9" depth x 18.2" h
(39.4 x 30.2 x 46.2 cm)
Doors and Drawer: Key-locked
Countertop: Stainless steel with 4" (10.2 cm) backsplash and .5" (1.3 cm)
spillproof lip
Finish: Powder coat
Weight:
244-181: 1917 lb (869.5 kg)
244-182: 2815 lb (1277 kg)
244-181
Cabinet, Generator and Storage, .5" lead
244-182
Cabinet, Generator and Storage, 1" lead
LEAD-LINED
GENERATOR AND STORAGE CABINET
Configuration drawings with
detailed dimensions available
for each cabinet at
www.biodex.com/cabinets.
